1. General teatures & merit

- Approximate cycle time : 8 Batteries / Min. of LN3 Battery
• 1st station : 5 surfaces washing with compressed water including water level sensor in the water tank
• 2nd station : 5 surfaces washing with compressed water including water level sensor in the water tank
• 3rd station : 6 surfaces washing with compressed water including heater and water level sensor in the water tank
• 4th station : 6 surfaces air blow
• 5th station : 6 surfaces heat blow

2. Machine details

- Applicable battery size : L185 - 410, W125 - 180, H170 - 250 (in mm)
- Air part : SMC
- Main power : 40kW
- Control PLC : MITSUBISHI (USER OPTION)
- Approx. size & weight : L7,020 × W1,970 × H2,450mm / 3,100kg

3. Utility
