1. General teatures & merit
- Cycle Time : Up to 8 batteries / Min.(with 6 heads) based on LN3 battery
- Fully automatic operation in each station
- Plug setting heads are set and moved by servo motors which enables easy and quick changeover in touch screen.
- Replaceable heads enable to screw different type of plug.
- Bowl feeder for each plug type is necessary (Option).
- NG detection is by checking torque at each head.
2. Machine details
- Applicable battery size : L185 - 410, W125 - 180, H170 - 250 (in mm)
- Air part : SMC, FESTO(USER OPTION)
- Main power : 3kW
- Control PLC : MITSUBISHI, Touch screen : PROFACE or MITSUBISHI
USER OPTION : ALLEN BRADLEY, SIEMENS and other Brands
- Sensor : KEYENCE, OMRON, MITSUBISHI (USER OPTION)
- Approx. size & weight : L2,500 x W2,500 x H2,200mm / 1,450kg
|Standard electrical power||220V / 380V / 440V * 3-phase * 50 / 60Hz(USER OPTION)|
|Compressed air||5 ~ 6kg / ㎠|
